Delta VFD015M43B

Delta VFD015M43B

235,00 د.إ

Delta VFD015M43B

Delta Products AC Drives, VFD-M Series Input Voltage: Single phase 380V, Applicable motor capacity : 2 HP(1.5 kW)

The VFD‑M series drives from Delta feature a compact design that is ideal for small and medium horsepower applications. VFD‑M drives are designed to provide ultra‑low‑noise operation, and include several innovative technologies that reduce interference.

,

Description

Specifications
  • Manufacturer: DELTA
  • VFD015M43B
  • Series Name : VFD
  • Applicable motor capacity : 2 HP(1.5 kW)
  • M Series
  • Input Voltage: Single phase 230V
  • Version Type : A
  • General Sensorless Vector Control Micro Drives
  • Voltage Class 380V Class
  • Model Number VFD-XXXM: 015
  • Max. Applicable Motor Output (kW): 1.5
  • Max. Applicable Motor Output (hp): 2.0 Output Rating:-
  • Rated Output Capacity (kVA):3.1
  • Rated Output Current (A): 4.0
  • Maximum Output Voltage (V): 3-phase Proportional to Input Voltage
  • Output Frequency (Hz): 0.1~400 Hz
  • Carrier Frequency (kHz): 1-15
  • Input Rating
  • Rated Input Current (A): 5.7
  • Rated Voltage, Frequency: 3-phase 380-480 VAC, 50/60Hz
  • Voltage Tolerance: ± 10% (180~264 VAC)
  • Frequency Tolerance: ± 5% (47~63 Hz)
  • Cooling Method: Fan Cooled



Additional information

Weight 1,5 kg
Dimensions 8,5 × 14,2 × 11,3 cm
