Description
Specification
Power Supply Voltage: 24VDC (-15%~ 20%) (the counter-connection protection towards the DC input power polarity is included
Motion Specifications: Within 5ms of the momentary power loss, the device will keep on operating
Maximum Power Consumption: 1w
Insulation Resistance : Above 5 megohm (500VDC between the ground and all the I/O points)
Noise Immunity: ESD(IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge
EFT(IEC 61131-2, IEC 61000-4-4): Power Line: 2KV, Digital I/O: 1KV, Analog & Communication I/O:1KV
Damped-Oscillatory Wave: Power Line: 1KV, Digital I/O: 1KV
RS(IEC 61131-2, IEC 61000-4-3): 26MHz~1GHz, 10V/m
Grounding: The diameter of the grounding wire cannot be smaller than that of terminals L and N (if numerous PLCs are used at the same time, make sure that each PLC is grounded respectively to the ground poles
